Z10
The groundbreaking Z10 with P.R.G. for hot and cold brew specialty coffees
A masterpiece of Swiss engineering, the new Z10 doubles the range of specialty coffees. At the touch of a button it prepares the full spectrum of hot drinks from intense espresso to on-trend flat white. It also opens up a whole new dimension in the enjoyment of coffee with the introduction of cold brew specialties. This is made possible thanks to the Product Recognizing Grinder (P.R.G.), which recognizes the chosen specialty and instantly and precisely adjusts the fineness of grind accordingly.
Z10 - Aluminium White (NAA)
Art. No. 15361
The new Product Recognizing Grinder (P.R.G.)
To ensure the optimum grind for every specialty, JURA engineers developed the Product Recognizing Grinder (P.R.G.). The electronically controlled high-performance grinder adjusts in a fraction of a second to the predefined consistency of grind – much more quickly and frequently than could be done manually. Its spectrum ranges from very fine for short classics to very coarse for long specialties. But coffee lovers don’t need to worry, because the adjustment takes place automatically every time a beverage is prepared and, if preferred, can also be individually selected before each preparation with the Aroma Selection feature.
Cold brew – extreme freshness
Thanks to the Cold Extraction Process, the Z10 prepares genuine cold brew specialties. While many conventional cold coffee drinks consist mostly of hot-brewed coffee which is then chilled, in the Z10 extraction takes place with cold water, pulsed at high pressure, and more coarsely ground coffee. The end result is a natural, energizing and refreshing beverage in which the fruity aromas of the coffee can be fully enjoyed without being overwhelmed by bitters. Anything else would just be a cold coffee.

Eighth-generation brewing unit
The brewing unit is the most important part of any automatic coffee machine. For the Z10, JURA has created the eighth-generation brewing unit. With its unique 3D brewing technology, it allows the water to flow evenly through the ground coffee at multiple levels. This makes the most of the aroma, both in hot specialties and with cold brewing.

Lasting elegance
Design and the careful choice of materials play an important role in product durability. JURA always strives to achieve a design that people will be proud to own and that will still look fresh and modern after many years. Uncompromising quality, durable, high-quality materials and maximum engineering precision guarantee both culinary and aesthetic excellence throughout the lifetime of the machine. The complex convex-concave aluminum front panel demonstrates the very highest standard of craftsmanship. The water tank with its elegant wave design and the harmonious filter casing are just two examples of the attention paid to what might seem like small details. As soon as you touch the Z10, you sense what true worth means to JURA.

For special indulgence
A syrup attachment for the dual spout is the perfect accessory for the Z10, enhancing the speciality range of the premium automatic coffee machine with subtly sweetened milk foam. The attachment means that every speciality – be it Hot Brew or Cold Brew – can be enjoyed with a slightly-sweet to sweet flavour. Enjoy tasting a wide range of pleasures, with a total of 40 specialities showing the true genius of the Z10.

Z10: Specifications
| 特製咖啡數量 | 40 |
|---|---|
| 義式濃縮 | |
| Cold Brew 義式濃縮 | |
| 2 × 義式濃縮 | |
| 咖啡 | |
| Cold Brew 咖啡 | |
| 2 × 咖啡 | |
| Americano | |
| 2 x Americano | |
| Lungo | |
| 2 x Lungo | |
| 雙份義式濃縮 | |
| 大壺咖啡 | |
| 告爾多 | |
| Cold Brew 告爾多 | |
| Sweet 告爾多 | |
| 義式濃縮瑪琪雅朵 | |
| Cold Brew 義式濃縮瑪琪雅朵 | |
| Sweet 義式濃縮瑪琪雅朵 | |
| 拿鐵 | |
| Cold Brew 拿鐵 | |
| Sweet 拿鐵 | |
| 拿鐵 Extra Shot | |
| 卡布奇諾 | |
| Cold Brew 卡布奇諾 | |
| Sweet Cappuccino | |
| 卡布奇諾 Extra Shot | |
| 馥芮白 | |
| Cold Brew 馥芮白 | |
| Sweet 馥芮白 | |
| 馥芮白 Extra Shot | |
| 拿鐵瑪琪雅朵 | |
| Cold Brew 拿鐵瑪琪雅朵 | |
| Sweet 拿鐵瑪琪雅朵 | |
| 拿鐵瑪琪雅朵 Extra Shot | |
| 奶泡 | |
| Sweet 奶泡份數 | |
| 牛奶 | |
| Sweet 牛奶份數 | |
| 熱水 | |
| 綠茶沖泡用熱水 |
| Cold Extraction Process | |
|---|---|
| Sweet Foam 功能 | |
| Automatic Grinder Adjustment (A.G.A.) | |
| 主動咖啡豆監控 | |
| 牛奶/奶泡自動切換 | |
| 與家用網路 Wi-Fi 連線 | |
| 供貨內容包含發射器 | Wi-Fi Connect |
| 研磨裝置 | Product Recognising Grinder (P.R.G.) |
|---|---|
| 已研磨咖啡的粉倉 | |
| 淡式濃縮咖啡功能 | |
| 脈衝提取工藝(P.E.P.®) | |
| 可變沸煮單元 | 5 – 16 g |
| 高性能泵,15 巴 | 1 |
| 熱塊加熱系統 | 1 |
| 液體系統 | 1 |
| 牛奶系統/可更換牛奶噴嘴 | HP3 / CX3 |
| 顯示幕 | 4.3 寸彩色觸控顯示幕 |
|---|---|
| 保存飲品、豐富飲品種類、對飲品進行個性化設定 | |
| 可編程設定和獨立調節的咖啡水量 | |
| 可編程設定和獨立調節的咖啡濃度 | 10 級 |
| 研磨度可單獨程式設計 | 5 級 |
| 沸煮溫度可編程設定 | 3 級 |
| 牛奶量/奶泡量可編程設定 | |
| 牛奶/奶泡溫度可編程設定 | 10 級 |
| 熱水溫度可編程設定 | 3 級 |
| 相容 J.O.E.® | |
| Rotary Switch |
| 智能水系統(I.W.S.) | |
|---|---|
| 過濾器濾芯 | CLARIS Smart+ |
| One-Touch 牛奶系統清潔(自動) | |
| 內建沖洗、清潔以及除垢程序 | |
| 實時監控剩水盤 | |
| JURA 衛生:經過 TÜV 認證 |
| 節能模式(E.S.M.©) | |
|---|---|
| Zero-Energy Switch 或電源開關 | |
| 可通過編程設定的關機時間 |
| 3 mm 凹凸鋁合金面板 | |
|---|---|
| 杯子照明,琥珀色/白色 | |
| 水箱照明,藍色 |
| 高度可調整/寬度可調整的組合出口 | 3 – 5.9 in / 0.9 – 2 in<br/>78 – 150 mm / 24 – 50 mm |
|---|---|
| 高度可調整的熱水出口 | 3.2 – 6.1 in / 82 – 154 mm |
| 水箱容量 | 81 oz / 2.4 l |
| 咖啡渣盒(份數) | 20 |
| 咖啡豆倉容積 | 10 oz / 280 g |
| 線纜長度 | 47 in / 1.2 m |
| 電壓/額定功率 | 120 V / 1450 W |
| 電流强度 | 10 A |
| 待機功率 | 0 W |
| 重量 | 27 lbs / 12.3 kg |
| 尺寸(寬 × 高 × 深) | 12.6 in × 14.3 in × 16.5 in<br/>32 cm × 36.3 cm × 47 cm |
| 商品編號, 産品名稱 | 15361, 白鋁 (NAA) |
| EAN 條碼 | 7610917153619 |
| 生産國 | Made in Switzerland |
| 型號生産年份 | 2021 |
| 咖啡粉匙 | |
|---|---|
| 組合流出口糖漿容器 | |
| 牛奶軟管(含接頭) | |
| 牛奶系統清潔用容器 | |
| 牛奶系統清潔劑,迷你清潔片 | |
| 三相清潔片 | |
| 過濾器濾芯 CLARIS Smart+ | |
| 過濾器延長元件/過濾器套 | |
| 操作說明書 | |
| 保固條件 |
Z10 (NAA) Instructions for Use EN
Changing the filter
Thanks to the integrated RFID (Radio-Frequency-Identification) chip, the CLARIS Smart continuously records information about filter use and alerts the user when the filter capacity has been used up. CLARIS Smart is automatically detected by the coffee machine and water is automatically routed through it.
Descaling the machine
Scale is the biggest enemy of any appliance that uses water. Only use JURA descaling tablets, which remove scale gently to extend the life of your coffee machine.
Cleaning the machine
Cleaning extends the life of your coffee machine and keeps the coffee quality at the highest level. Only use JURA cleaning tablets, which are specially designed to work with the cleaning programme.
Cleaning the milk system
It's easy to keep the milk system in the dual spout hygienic and working perfectly. Just remember to clean the milk system every day if you have been preparing milk. This only takes about two minutes. Only use JURA milk system cleaner, which is specially formulated to clean the milk system.
